Pentair Sparus III Variable Speed & Flow Pump 1.5 HP
The SPARUS™ III Variable Speed & Flow Pump is engineered for aquaculture systems requiring stable, precise water flow. Featuring patented sensorless flow technology, integrated automation, and app-based control, Sparus III delivers reliable performance with significant energy savings. Available in 1.5 HP and 3.0 HP models.
Features
• Patented automated flow control: Maintains consistent flow for peak system efficiency and component longevity.
• Variable speed operation: Delivers up to 90% energy savings compared to single-speed pumps.
• Designed for aquaculture: Optimized for continuous-duty operation in demanding aquatic environments.
• DOE compliant motor system: Updated motor, drive, and hydraulics meet U.S. Department of Energy regulations.
• Onboard automation: Integrated I/O board with two relays for controlling auxiliary equipment.
• Remote monitoring & control: Easily manage schedules and pump operation using the Pentair Pool / Home App.
• WiFi & Bluetooth® connectivity: Enables remote access and automatic over-the-air software updates.
• Optional touchscreen interface: Adds flexible on-site control when required.
The SPARUS™ III Variable Speed & Flow Pump delivers unmatched control, efficiency, and performance for demanding aquaculture applications. Built with advanced Constant Flow Technology™, this intelligent pump automatically adjusts speed to maintain your desired flow rate. Ensuring optimal system performance while minimizing energy consumption.
SPECIFICATIONS
• Horsepower: Up to 3 HP.
• Flow Control: Constant Flow or Variable Speed.
• Inlet/Outlet:2” connections.
• Material: Corrosion-resistant thermoplastic with stainless steel components.
• Seal type: Type 6 mechanical seal with ceramic, stainless steel, and EPDM components.
• Strainer: High-density polyethylene with clear thermoplastic lid.
• Motor type: High-efficiency, totally enclosed fan-cooled (TEFC).
• Motor enclosure rating: NEMA Type 3 / IPX5.
• Motor frame: NEMA 56.
• Thermal protection: Integrated motor control circuitry.
• Warranty: One-year.
• Pump programming: The Pentair Home App is required to operate the Sparus III pump when used without the optional touchscreen.
| Model | HZ | HP | Voltage | Phase | FL Amps | Motor | Dimensions | Port Size | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 013084 | 50/60 | 1.5 | 115/208–230 | 1 | 12/6.4–5.9 | TEFC | 24.9" x 11.7" x 12.0" | 1.5" x 1.5" or 2" x 2" |
